Per Unit Analysis for Single and Three Phase Systems
Per Unit Analysis for Single and Three Phase Systems
Original price was: £425.£29Current price is: £29. ex Vat
Take This Course OR
1 Year Access
Intermediate
4 Students -
6 hours, 4 minutes
Learning Outcome
- Learn how per unit analysis is performed and how equipment manufacturers use it to rate their products
- Learn the knowledge and expertise needed to succeed in electrical engineering
- Recognise the benefits of performing per-unit analysis on single- and three-phase systems
- Possess an in-depth understanding of the theory of normalisation and its implementations
- Become familiar with the way equipment manufacturers utilise and grade their products
- Learn how to transition to and from the Per Unit system
- Know the steps involved in modifying the base values of per unit systems
Description
Maintenance of electronic devices and circuits can be quite risky if you don’t know the voltage of the device. You can use per unit analysis to determine voltage. Also per unit values help to calculate other system values. Learn how to conduct per unit analysis from this Per Unit Analysis for Single and Three Phase Systems course and be able to handle the voltage of your device safely.
In this Per Unit Analysis for Single and Three Phase Systems course, you will learn what PU analysis is, different types of PU analysis and its benefits. You will learn single-phase and three-phase system analysis, the normalization process and system circuit analysis. You’ll also learn about the safety measures for electrical analysis.
This course will train you to conduct per unit analysis for any system, with step-by-step video guidance. Whether you are looking to take your skill to the next level, or kickstart a career in the electrical industry, this course introduces techniques that will help you achieve that in no time.
Course design
The course is delivered through our online learning platform, accessible through any internet-connected device. There are no formal deadlines or teaching schedules, meaning you are free to study the course at your own pace.
You are taught through a combination of
- Video lessons
- Online study materials
Will I receive a certificate of completion?
Upon successful completion, you will qualify for the UK and internationally-recognised CPD accredited certification. You can choose to make your achievement formal by obtaining your PDF Certificate at the cost of £9 and Hard Copy Certificate for £15.
Why study this course
It doesn’t matter if you are an aspiring professional or absolute beginner; this course will enhance your expertise and boost your CV with critical skills and an accredited certification attesting to your knowledge.
The Per Unit Analysis for Single and Three Phase Systems is fully available to anyone, and no previous qualifications are needed to enrol. All One Education needs to know is that you are eager to learn and are over 16.
Course Curriculum
| Per Unit Analysis for Single and Three Phase Systems | |||
| Module 01: Introduction | 00:06:00 | ||
| Module 02: Per Phase Analysis (R1) | 00:34:00 | ||
| Module 03: The Normalization Process | 00:50:00 | ||
| Module 04: Single Phase PU Example (R1) | 00:10:00 | ||
| Module 05: Three Phase PU Analysis & Transformer Configurations Part 1 | 00:52:00 | ||
| Module 06: Three Phase PU Analysis & Transformer Configurations Part 2 | 00:44:00 | ||
| Module 07: Three Phase PU Analysis & Transformer Configurations Part 3 | 00:51:00 | ||
| Module 08: Change of Bases | 00:16:00 | ||
| Module 09: System Circuit Analysis | 00:27:00 | ||
| Module 10: Three Phase PU Example | 00:19:00 | ||
| Module 11: A Per Unit Example! | 00:09:00 | ||
| Module 12: A Per Unit Example Problem | 00:22:00 | ||
| Module 13: A Per Unit Example | 00:24:00 | ||
| Assignment | |||
| Assignment -Per Unit Analysis for Single and Three Phase Systems | 00:00:00 | ||
