Short Circuit Analysis for HV Three Phase Systems

  • Instructor Unique
  • Original
  • Video Training

Short Circuit Analysis for HV Three Phase Systems

  • Instructor Unique
  • Original
  • Video Training
Short Circuit Analysis for HV Three Phase Systems
cpdacree aoth ukrlp 24hs fullonline 14days
Short Circuit Analysis for HV Three Phase Systems

Get access to 5000+ courses including this for only £49. Learn More.

Learning Outcome

  • Understand how to identify symmetrical components.
  • Acquire knowledge on the methodologies of per unit system faults.
  • Know the basic concepts of fault studies on a high-voltage three-phase system.
  • Gain a solid understanding of balanced three-phase systems.
  • Develop knowledge on how the MVA base is calculated and much more.

Description

An electrical short circuit is one of the most common yet deadly hazards in the electrical industry. To prevent these accidents knowing to analyze electrical devices is a must. Learn how to analyze short circuits and avoid accidents from this Short Circuit Analysis for HV Three Phase Systems course and be able to handle the voltage of your device safely.

In this Short Circuit Analysis for HV Three Phase Systems course, you will learn about the symmetrical and asymmetrical system, system modelling and analyzing system faults. You will learn to use symmetrical components for a three-phase system and get a quick review of per phase and per unit methodology. You’ll also learn about the safety measures for electrical analysis.

This course will train you to analyze short circuits and repair faults, with step-by-step video guidance. Whether you are looking to take your skill to the next level, or kickstart a career in the electrical industry, this course introduces techniques that will help you achieve that in no time.

Course design

The course is delivered through our online learning platform, accessible through any internet-connected device. There are no formal deadlines or teaching schedules, meaning you are free to study the course at your own pace.

You are taught through a combination of

  • Video lessons
  • Online study materials

Will I receive a certificate of completion?

Upon successful completion, you will qualify for the UK and internationally-recognised CPD accredited certification. You can choose to make your achievement formal by obtaining your PDF Certificate at the cost of £9 and Hard Copy Certificate for £15.

Why study this course

It doesn’t matter if you are an aspiring professional or absolute beginner; this course will enhance your expertise and boost your CV with critical skills and an accredited certification attesting to your knowledge.

The Short Circuit Analysis for HV Three Phase Systems is fully available to anyone, and no previous qualifications are needed to enrol. All One Education needs to know is that you are eager to learn and are over 16.

Course Curriculum

Short Circuit Analysis for HV Three Phase Systems
Module 01: Introduction to Short Circuit Analysis for HV Three Phase Systems course 00:07:00
Module 02: Short Circuit & Fault Analysis Overview 00:12:00
Module 03: Per Phase Analysis 00:33:00
Module 04: Per Unit Analysis 00:22:00
Module 05: Change of Base 00:11:00
Module 06: Transformers & Per Unit Analysis 00:31:00
Module 07: Symmetrical Components 00:30:00
Module 08: Asymmetrical Three Phase Fault Analysis 00:52:00
Module 09: System Modeling 00:30:00
Assignment
Assignment -Short Circuit Analysis for HV Three Phase Systems 00:00:00
