Understand Piping & Instrumentation Diagrams (P&IDs) teaches how to read and interpret engineering schematics, showing piping, equipment, instruments, and control systems for process industries.
Save 93.18 % - OFFER ENDS SOON
Or
1 Year Access
Intermediate
116 Students
8 hours, 26 minutes
Get access to 5000+ courses including this for only £49. Learn More.
Master P&ID diagrams and gain the skills to confidently interpret engineering drawings used across modern industries. This course introduces piping systems, instrumentation basics, and essential instrument symbols, helping learners understand how equipment, pipelines, and control devices work together in plant design and process engineering.
Build a strong foundation in process control through practical lessons covering control theory, Basic Process Control Systems (BPCS), Advanced Process Control, and Safety Instrumented Systems (SIS). Learn how industrial piping networks operate while exploring designation codes, alarms, interlocks, and real-world applications used in mechanical engineering projects.
Strengthen your expertise with hands-on practice reading P&ID diagrams and solving real-world examples. By the end of the course, you'll confidently analyze engineering drawings, identify instrument symbols, understand piping systems, and apply process engineering and process control concepts to support efficient plant design and industrial piping operations.
Learners complete an assignment designed to evaluate their understanding of the course content. The assignment is reviewed by qualified tutors who provide personalised feedback, allowing learners to demonstrate their applied knowledge and skills.
After completing the Understand Piping & Instrumentation Diagrams P&IDs course assessment, you will be eligible to receive a CPD-accredited certificate worth £9 from One Education to demonstrate your achievement.
The certificate is also available as a printed hard copy delivered by post for £15.
Understand Piping & Instrumentation Diagrams (P&IDs) provides learners with the knowledge to interpret and analyse technical drawings used in industrial processes. This course develops an understanding of piping systems, instrumentation symbols, and process flow essential for engineering and maintenance roles.
Studying Understand Piping & Instrumentation Diagrams (P&IDs) strengthens technical skills and improves confidence in reading complex engineering documentation. The course supports career development in industries such as oil and gas, manufacturing, and process engineering by enhancing practical workplace knowledge.
The Understand Piping & Instrumentation Diagrams (P&IDs) course has a total study time of 8 hours, 26 minutes. This comprehensive programme is designed for flexible learning, allowing learners to progress at their own pace while developing the skills to read and interpret piping and instrumentation diagrams, understand process equipment, instrumentation symbols, control systems, and industrial plant documentation.
The Understand Piping & Instrumentation Diagrams (P&IDs) course requirements are simple and suitable for beginners. Learners should have basic engineering or industrial process knowledge, an interest in plant operations, and a willingness to understand technical diagrams. Access to an internet-enabled device and commitment to practical learning are recommended for effective course completion.
This course teaches how to read, interpret, and understand Piping and Instrumentation Diagrams (P&IDs), including piping systems, process equipment, instrumentation symbols, control loops, valves, and industrial process flow.
No. It is suitable for beginners, although a basic understanding of engineering or industrial processes is helpful.
The course is delivered online, allowing you to learn at your own pace.
Yes. Practical P&ID interpretation exercises, symbol identification activities, and quizzes may be included to reinforce learning.
You will receive a certificate of completion after successfully finishing the course.
This course supports careers in process engineering, chemical engineering, mechanical engineering, instrumentation and control, plant operations, maintenance engineering, and industrial engineering.
